Rocco quoted me 450
What is the gl fitting for on the back of the isolating single cow?
3 Likes
Was going to do 24/40? Unless we wanted something else?
1 Like
3 Likes
I also gave a stainless 8qt trap , it has 1/2” straight flange and as soon as I can access a tig welder it will be kf25 flange
1 Like
@coppertop To combat the sink/over shoot problem I plan on adding a 200mm Liebig condenser with an 250mm vacuum assisted Erlenmyer flask just before the cold trap.
@Poizzin I’m impressed with the thickness of the HK glass!!
3 Likes
It’s to release vacuum only from the collection flask so you can pull it and change the flask.
3 Likes
Do you just plug the cap with something or how does that work?
Where do you pull vac from on this setup with only 1 port on the cold trap
@munkdooligan found a high temp GL plug he used for his Lab Society head. I’m thinking you just plug it with that, then loosen it to release vac after screwing down the valve.
3 Likes
You’d pull vac from the output joint. It would be hooked up to a glass joint cold trap or (my plan) a 24/40 to KF25 PTFE adapter that connects to the bellow hose which connects to the cold trap which connects to the pump. KF25 fittings from the monocow to the pump.
2 Likes
@anon60420198 I plan on hooking mine up to the Erlenmyer flask.
Here’s a cap from chemglass
New Chemglass CG-196-02 Series CG-196 Solid Cap, PTFE Seal, GL-18 Thread, PBT
1 Like
My 3way adapter and recieving flasks are not installed , in the process of cleaning them
2 Likes
I just got the kf25 to 24/40 adapters , waiting on a few items more to complete
1 Like
That’s what I use, good up to 200C, which is fine by that point on your condenser. I release vacuum at the pump, I have a 4-way kf25 adapter with a release valve and my gauge attached to it.
3 Likes
Come to think off iT
See If your artist can make a double Jacketed cold trap
So the outside skin can be cooled to i think that would be verrry gooood
Instead of deasy chaining
2 Likes
Good call!
Might be hard to fit the ice around the outside? I’ll toy with the idea
Does anyone make a heating mantle/jacket for the 2 liter or half gallon mason jars?
1 Like
Sous vide on Amazon with a water bath is probably a nice option
1 Like
Careful with those fuckers. They make you think they’re up to the job of heating and then crack on you when you least expect it. Almost lost a half gallon of oleoresin trying to heat in them and lost a half gallon of solvent just pulling it from the freezer, now I strictly use them for storage and only heat or freeze borosilicate.
5 Likes
