Lowest Micron With GL Fittings?

Hash and Stuff Distillation
, , ,
41

First official flush out of the eBay pump, no clue what they used it for before me.

image3024×4032 1.75 MB

40 microns and declining with FF-10 flushing oil. Going to run for an hour and then ballast for an hour. Then put regular vac oil in and see how we did. I wanted to do a kerosene flush but my pump has a plastic eye leve and heard it could damage it. If I get to <20 micron I’ll be. A happy man.

image3024×4032 2.69 MB

Update: reached 38 micron blanked off. I’m not exactly happy with it but it’s cleaned out atleast. Could be fittings, we have hooked up by the end of the week

1 Like
42

2 years on a cow and tubes… wtf was I thinking! (100 micron 180 Celsius) going to mains soon will update micron

image4032×3024 2.41 MB
image3024×4032 2.01 MB

Update: hitting mains at 180-185… it’s a beautiful thing.:yellow_heart: micron 85

4 Likes
43

That Alcatel needs a rebuild at 40 micron. I think anything above 15 micron on them pumps on clean oil is considered outta spec.

The 3 I had would constantly get to 6 micron.

You open the ballets when u flushed it? Most of my eBay pumps took a minimum of 3x flushes to get them to low micron.

2 Likes
44

I ran hot with oil in first, then only flushed/ran it one time for an hour because I was short on time with ballast running half the time . I will continue to flush after this run. I pulled 30 microns less after first flush. Thanks for the tips

And thanks for this kick ass cold trap​:+1::sunglasses:

I’m just happy I’m moving forward and not backward! I’ll post 2nd run micron tomorrow after flushes.

1 Like
45

Why is my boiling flask reacting a lot then goes to Standstill every 20-30 secs…?

My spd is not clogged

Stir bar? I have like a .8 inch stir oval stir bar wondering if that is too small…

46

@Distillight

1 Like
47

Think it had something to do with head temperature, I wrapped it in foil and looked to be a consistent boil. I run a plug on my head so no clue.

Although my run took me around 7-8 hours, I had mantel at 215 to do a quick first pass. I got amber distillate bulk but the heat didnt seem like it helped much. might lower down to like 205 on my first passes now

48

It’s usually the larger the better with stirbars. I have some 2 inch ones and even a rare earth magnet one if you’re interested. I even have a great Edwards vac gauge you might want to add to your fullbore setup to allow for lower vac.

Hit me up in the dms.

2 Likes
49

What edwards gauge the p3 @Renchi?

2 Likes
50

@The_Lone_Stiller

Yes, that one exactly.

51

How much @Renchi?

52

@The_Lone_Stiller

I sent you a dm

53

The gauge goes for 750 if anyone is interested. Hit me up in the dms.

1 Like
54

I had good experiences with using LN2 in the cold trap. Like this I get down to 1 micron with fresh pump oil. I have a 2 liter setup too and had similar problems in the beginning. I never had the problem - often warned about that it may condense oxigen, never saw any blue liquid in the cold trap. Done many times, so i guess its safe.

1 Like
55

What female fitting is on the stainless hose? I have several of these units I’m trying to connect to kf/sanitary flanges. I’m thinking about getting some of these and then go npt to flange. Do you think these would work or do you have a better suggestion? Female Flare (1/4 FFL) to 1/4" Male NPT Adapter

56

1/4” JIC hose.

1/4 JIC matches well enough on the SAE flare.

37° vs 45° taper…only works at 1/4”

see: 1/4" FJIC to 1/4" SAE and gaskets for dry ice

Try SS304 KF25 Fitting to Male JIC Adapters | USA Lab

2 Likes
57

37 degrees of flare you say?

IMG_3446
IMG_34461280×720 133 KB

3 Likes
58

Thank you very much I thought they were SAE but wasn’t sure.

59

This is such a good fittings meme. Thank you

60

If you can, use something along the lines of the USA labs one piece adapter (you can get them for tri-clamp too), because NPT sucks!

See: Switching from NPT to Compression Fittings

1 Like
