Before
after
9 Likes
Requires almost 1000 psi, so asme would be hard pressed to approve it
3 Likes
Hard mmeeeeehhhhh
5 Likes
Not really any reason why getting a 1000 psi vessel built for butane would be any different than any other fluid. It’s not lethal service
3 Likes
Hi! I was away from the Future for some time but I do have a lot of info on the membranes . Went From solvent recovery to fractions to total disappointment and back to The apparition of What membrane tech can DO!!!
As of today I tried almost 30 different membranes so I can put some light on the subject.
Color is NOT a good representation of the final quality I learned it the hard way - WATER is present ( picked up from the biomass ) so sugars are easily slips in to the permit stream And Can make it yellowish (300-500 MWCO membranes was used for fractionation ) … Permit was yellow but contained mostly the sugars and lipids based on the COA results …my
Confusion was coming From the manufacture stated WMCO on the membranes (300-500 daltons) And surly I didn’t realize what this numbers are for the water and Salts and not for the solvent and Acidic cannabinoids surrounded by lipids and fats !
So I and up with few kilos of junk after final evaporation…(cbda was in 3% range and this was important finding !!!)
I did change The
sequence Of the Filtration and WOW - my bad results become a great results all the sugars together with the portion of lipids and fats are passing to the permit and the good stuff (cleaner cannabinoids fraction ) going to the reject! And reject is my keeper.
So now all the sugars fractions going to the solvent recovery membranes with the junk discarded and the sugar FREE former reject going to the next stage of
Membrane filtration.
I hope it helps
To be continued…
8 Likes
Sorry for the gramma
This was heptane crude which was dissolved 20:1 in ethanol, heptane wont pull sugars. I already have testing and have confirmed cannabinoid passage.
2 Likes
My was directly from the Methanol extraction
1 Like
Any specific reason you are not filtering in heptane?
I get Best results so far With the last filtration of heptane
Because most ppl are using ethanol
1 Like
Sorry get confused on the heptane crude…
If you are interested in the Nanofiltration please come see my lecture this week.
Registration is free.
Registration link: Trends in Cannabis Extraction: Scaling Up and Purifying for Desired End Products
November 18th 2020 8AM PST
3 Likes
That color remediation though
Warm extracted ethanol denatured with heptane crude winterized with a membrane
2 Likes
Are those in solution or straight oil?
1 Like
Solution still, haven’t finished running it yet
I’ll recover it on the FFE tomorrow
2 Likes
Looks like I’m passing barely any chlorophyll if any
Gonna run it through my solvent recovery membranes in a little
Should have analytics by Wednesday
2 Likes
Is the bottom picture the oil or still in solution?
Both are still in solution
Bottom is starting crude
Top is winterized
2 Likes
Ill be handling recovery with my membranes later and will get pics with no solvent once recovery is finished
3 Likes
